CNC Board
Showing 1-20 of 73 products
iPhone logic boards from the 8 generation onward are two boards soldered face to face through an interposer ball array. When one layer is destroyed, the surviving layer can be paired with a CNC-machined donor — milled clean of old solder and flat, ready to reball.
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 2 left
Only 1 left
Only 1 left
Only 2 left
How to choose CNC Board
Order the opposite half to whichever layer survived on the customer board. You will also need the middle-layer reballing stencil for that model plus paste, flux and hot air — the CNC board removes the cleaning-up stage, not the reballing.
CNC Board frequently asked questions
What is a CNC board used for?
It is a prepared donor board layer. When one half of a stacked iPhone board is damaged beyond repair, you keep the good half and rejoin it to a CNC-milled donor rather than scrapping the phone.
Do I need a reballing stencil as well?
Yes. The two layers rejoin through an interposer ball array, so the middle-layer stencil for that model is required. The CNC board only saves you milling the donor clean yourself.
Is this work realistic for a general repair shop?
It is specialist. It needs hot air with fine control, a middle-layer stencil, magnification and practice. Shops that do it well treat stacked-board repair as its own discipline.
